K-PO - SW3M

Frequency range:
Up to 1 GHz

    VSWR: 0-500 MHz: >=1.05 / 500 MHz - 1 GHz: >=1.15 / 1-1.5 GHz : >=1.25
    Impedance: 50 Ohm
    Insertion loss: 0-500 MHz: >=0.05dB / 500 MHz - 1 GHz: >=0.1dB
    Isolation: 0-500 MHz: <=70dB / 500 MHz - 1 GHz: <=60dB
    Power range: 0 - 30 MHz: 1.5 kW / 30 - 200 MHz: 1 kW / 200 - 500 MHz: 500 W / 500 MHz - 1 GHz: 250 W

Mechanical data

    Connector(s) type in: UHF (PL) female
    Connector(s) type out: UHF (PL) female
    Length: 100 mm
    Height: 80 mm
    Width: 30 mm
    Weight: 550 gram
